BX-STRONG-AGM-ZKIT

CAME actuator for leaf gates set, max 800kg,

Mark: Came, Max. wing length: 4m, Module of the gear comb: mod 4, Recommended weight of the wing: 400kg, End point: Magneticky koncový doraz, Frequency (MHz): 433, Code type: Multi (fix/rolling), Drive slowdown: Drive decelerate before endpoint, Motor power supply: AC 230V, Performance: 520W, Force: 800N, Speed: 10,5 m/min, Power supply: AC 230V, Controller: ZBX7N, Master/Slave: Áno, Capacitor: 20uF, Protection level: IP44, Encoder: Áno

€388,58
without VAT
€477,95
with VAT
Tax included Shipping calculated at checkout.
PCS
Stock availability

Kontakt

Add some general information about your delivery and shipping policies.

lubomir.petruska@umakov.sk
+421915093533 +393483490444
Popis Parametre Na stiahnutie Časti zostavy Katalógový list Povinný sortiment Doporučené produkty Alternatívne produkty V setoch

Parametre

Mark
Information about producer of product
Came
Max. wing length
Maximum wing length for the given drive
4m
Module of the gear comb
Určuje kompatibilitu hrebeňa s pastorkom motora.
mod 4
Recommended weight of the wing
Odporúčaná hmotnosť krídla brány pre správnu funkčnosť pohonu.
400kg
Frequency (MHz)
Určuje frekvenciu ovládača a riadiacej elektroniky.
433
End point
Informácia o potrebe koncových dorazov brány pri zvolenom pohone.
Magneticky koncový doraz
Code type
Typ kódu pre správnu kombináciu ovládača s elektronikou.
Multi (fix/rolling)
Drive slowdown
Information about the drive slowdown before the end position
Drive decelerate before endpoint
Motor power supply
Drive-unit power supply
AC 230V
Performance
520W
Force
800N
Speed
Parameter of the drive feed speed
10,5 m/min
Power supply
Drive-unit power supply
AC 230V
Controller
ZBX7N
Master/Slave
Áno
Protection level
IP44
Encoder
Áno
Capacitor
20uF

Na stiahnutie

PDF
Document for download

Časti zostavy

Elektronika pre posuv.bránu - rozšír.funkcie

Electronics for sliding gates - extended functions ZBX-7N

1 pcs
Mark
Came
Rádiová karta 433,9 MHz

Radio card 433,9 MHz AF-43-S

1 pcs
Mark
Came
Came Diaľkové ovládanie rolling code, 4CH, CAME

Remote controller CAME TOP roling code, 4CH, CAME TOP44RBN

1 pcs
Mark
Came
Frequency (MHz)
433
Code type
Rolling
Fotobunka na omietku max. 10m Fotobunka na omietku max. 10m

Photocell for plaster montage max. 10m DIR-10

1 pcs
Mark
Came
Power supply
12-24V AC
Protection level
IP54

Katalog

Doporučené produkty

Univerzálny podstavec pre pohony posuvných brán

Universal stand for sliding gate drives UNI-STAND

Material
Stainless steel AISI 304
Mark
Rollkit
€45,15
without VAT
€55,53 with VAT
In stock (517 units)
PCS
Technical info
CAME pohon pre posuv. brány, set, max 800kg,
umakov-sk

CAME actuator for leaf gates set, max 800kg,

€388,58
View product
